Heavy-duty 1-Ton aluminium steering flip kit Barnes 4WD Lift 2,5-6"

• Steering link material: solid 7075 aluminium
• Steering link outer diameter: 1.5"
• Type: heavy-duty 1-Ton steering linkage kit
• Drag link in the flip configuration
• GM 1-Ton-standard steering ends
• Lighter and more flexible construction than steel steering links
• Improved steering linkage angles after installing a suspension lift
• Increased drag link protection against off-road obstacles
• Designed for off-road driving and modified steering systems

In the box:

• Barnes 4WD 1-Ton aluminium tie rod
• Barnes 4WD 1-Ton aluminium flip drag link
• 2 GM 1-Ton offset steering ends with right-hand thread
• GM 1-Ton offset steering end with left-hand thread
• GM 1-Ton standard steering end with left-hand thread
• Steering stabilizer mount
• Tapered steering knuckle insert

Notes:

• Installation requires drilling the passenger-side steering knuckle arm hole to 7/8"
• Factory wheels require 1.5" wheel spacers
• Fits aftermarket wheels with 4.5" backspacing or less
• Depending on the wheel design, additional spacers or steering stop adjustment may be required
• Steering stabilizer mounts positioned outside the factory location may come into contact with the steering links
• Before driving, check the full steering and suspension travel and make sure the steering links do not interfere with the wheels or other components
